GY-HM620E

MFR #GY-HM620E  BLK #197-0299

Special Price

Not in stock

Quick Overview

  • Handheld Camera
  • AVCHD 28Mbps/H264 50Mbps
  • 3CMOS 1/3" - 0.15LUX
  • 29-667mm 23X
  • 1920x1080 50P/60P
  • SD-HC/SD-XC
  • HD/SD-SDI & HDMI Output
  • XLR Inputs

GY-HM620E

The GY-HM620 is an advanced handheld ProHD camera that delivers unsurpassed imagery and offers features for news, sports, and independent production. Based on JVC's popular GY-HM600, the new 620 has upgraded CMOS devices for greater sensitivity and a brighter LCD display for outdoor daylight viewing. Versatile and extremely easy to use, there's no better camera for fast paced HD field production.

  • Newly designed 1/3-inch 12-bit CMOS sensors (1920 x 1080 x 3)
  • F13 sensitivity (50Hz)
  • 23x Fujinon auto focus zoom lens with manual functions
    F1.6-3.0, 23x, f=4.1-94.3mm (35mm conversion: 29 to 667mm)
  • Optical image stabilizer
  • 3 position ND filter (1/4, 1/16, 1/64)
  • 0.45-inch 1.22M pixel colour viewfinder
  • Upgraded 3.5-inch 920K pixel LCD display with focus assist
  • SDXC/SDHC memory card recording (two slots for dual-backup, continuous recording)
  • Large file size support with SDXC card
  • 50Mbps H.264 Extreme High Quality mode (XHQ)
  • Multiple encoding formats:
    • HD MPEG2 (35/25/19Mbps)
    • AVCHD 1920x1080 60i
    • 1080/60p recording capability
    • SD H.264
  • Wide media format compatibility:
    • .MOV (Final Cut Pro)
    • .MP4 (XDCAM EX™)
    • AVCHD
  • Professional switch layout and comprehensive video settings
  • Pre Rec (retro) mode (15 sec.)
  • Interval (time lapse) recording
  • Built-in stereo microphone
  • 2-channel balanced audio inputs (mic/line switchable) w/phantom power supply
  • HD/SD-SDI, HDMI Outputs
  • Wired remote control connector
  • High performance 2D DNR

GY-HM620E

    STATUS

  1. Status

    NoView

    Camera Type

    Handheld Camera

    HD Camera

  2. VIDEO SPECIFICATIONS

  3. Video Format

    AVCHD 2.0(MPEG4/H.264) up to 28Mbps - 4:2:0/8bit - M2TS files

    JVC XDCAM EX HD(MPEG2 HD MP@HL) 35Mbps - 4:2:0/8bit - MP4 files

    JVC XDCAM EX HD(MPEG2 HD MP@HL) 35Mbps - 4:2:0/8bit - MOV files

    JVC H.264 XHQ 50Mbps - 4:2:0/10bit - MOV Files

    Video Resolution

    SD 480i NTSC(16:9)

    SD 576i PAL(16:9)

    HD 720: 1280x720pixels(16:9 aspect ratio)

    HD 1080: 1440x1080pixels(4:3 aspect ratio)

    HD 1080: 1920x1080pixels(16:9 aspect ratio)

    Slow Motion

    No

    Quick Motion - Time Lapse

    No

    Frame Rate

    24P/25P/30P/50i/50P/60i/60P @1920x1080Pixel
    50P/60P @1280x720Pixel
    50i @720x576Pixel
    60i @720x480Pixel

    Rec Media

    SD/SD-HC/SD-XC Card

    Simultaneous REC

    Yes

    Rec Time

    312min @24Mbps with 64GB REC-Media

    213min @35Mbps with 64GB REC-Media

    Pre Record

    Yes - 15sec

  4. LENS SYSTEM

  5. Sensor Type

    3CMOS

    Sensor Size

    1/3" (crop factor 7.21)

    Sensor Resolution

    2.2MP x3

    Lens Type

    Fixed

    Lens Manufacturer

    Fujinon

    Focal Length

    29mm to 667mm (35mm equivalent)

    Zoom

    23X

    Aperture

    Zoom out: F1.6 to F11
    Zoom in: F3.0 to F21

    Control Rings

    3 Rings(Zoom, Focus, Iris)

    Auto Focus

    Yes

    Image Stabilizer

    Yes

    Filter Diameter

    72mm

    ND Filters

    Yes

  6. CONNECTIONS

  7. Video outputs

    HDMI

    HD/SD-SDI (BNC) 4:2:2

    CVBS (Jack to RCA)

    Audio inputs

    3-PIN XLR Mic/Line

    Audio outputs

    Jack 3.5mm Stereo

    Jack to 2xRCA

    2CH Embedded Audio SDI

    2CH Embedded Audio HDMI

    PC Connections

    Mini-USB2.0

    Other Connections

    Remote Zoom (Jack 2.5mm)

    TC IN (RCA)

    TC OUT (RCA)

  8. GENERAL FEATURES

  9. Shutter speed

    1/4sec to 1/10000sec

    Min. Illumination

    0.15LUX

    Sensitivity

    F13

    Streaming

    No

    File Transfer

    No

    LCD

    3.5"

    Viewfinder

    0.45"

  10. MORE SPECIFICATIONS

  11. Power

    JVC SSL-JVC50 Type Battery

    Power adapter

    No. of battery slots

    1

    Power Consumption

    10W(7.2V/1.39A - 12V/0.84A)

    Warranty

    2-Years

    Country of Origin

    Japan

  12. PHYSICAL

  13. Total Weight (KG)

    2.4

    Total Dimensions (WxHxD) (mm)

    178x198x416

    Availability

    Usually in 9working days

GY-HM620E

  • Battery 4900mAh
  • AC adaptor
  • AC cable

GY-HM620E

Operation Manual

JVC_GY-HM620_Manual.pdf

General Features

JVC GY-HM620 Review
